GL Enhances T1 E1 Analyzer Products and Software - Ver 5.11

Welcome to the GL's Newsletter covering the latest products, features, and enhancements introduced to our versatile T1 E1 Analyzer product line (Ver 5.11).

New applications introduced to the T1 E1 Analyzer software are:

In addition to the above new applications, there are also significant enhancements introduced to existing applications. They include:

If you have our products or are interested in these features, please download or enquire about these enhancements.



A brief summary of the new features in the T1E1 Analyzer - 5.11 Release are provided below:

  • WCS SS7 Protocol Decode Agent

    The SS7 Protocol Decode Agent module monitors SS7 links, captures frame header information, decodes multiple SS7 protocol standards, filters user-specified protocol parameters, builds call detail records(CDRs) and streams the decoded fields and/or CDRs to the comma delimited files (CDR.CSV and/or FRAMES.CSV) over TCP/IP to remote site. It can also capture filtered data in real-time using layer filter and field filter keys.

    For comprehensive understanding of the product, please visit the WCS SS7 Protocol Decode Agent webpage.

  • WCS ISDN Protocol Decode Agent

    The ISDN Protocol Decode Agent module monitors ISDN links, captures frame header information, decodes multiple ISDN protocol standards, filters user-specified protocol parameters, builds call detail records(CDRs) and streams the decoded fields and/or CDRs to the comma delimited files (CDR.CSV and/or FRAMES.CSV) over TCP/IP to remote site. It can also capture filtered data in real-time using layer filter and field filter keys.

    For comprehensive understanding of the product, please visit the WCS ISDN Protocol Decode Agent webpage.



Other significant enhancements were introduced to the following applications:

  • Protocol Analyzers

    Significant enhancements have been introduced to the protocol analyzer product series. User can now add hyper channels with discontinuous (sparse) timeslots. For example, a PPP link on card #1 can have timeslots 1 to 15 and 17 to 31 (#1:1-15, 17-31). Similarly, any number of hyper channels can be build with such various combinations.

    The GUI part of the application that helps for protocol configuration now includes feature to edit decode parameters in *.ini file. This feature is now available for SS7, CDMA, CDMA on ATM, PPP, TRAU, and UMTS protocol analyzer decode engines.

    With Inverse Multiplexing in ATM (IMA) feature, two or more T1 circuits can be configured to form a high-speed connection of DS3 circuit. ATM cells are transmitted across multiple interfaces in a cyclical fashion, and recombined to form the original stream. The ATM, CDMA on ATM (A3 A7), and UMTS protocol analyzers now support decoding with the IMA option.

    For comprehensive understanding of the product, please visit the Protocol Analyzers webpage.

  • Multi-Class MLPPP Emulator

    User can add hyper channels with discontinuous (sparse) timeslots. NCP Configuration in PPP simulation allows selecting NCP parameter per link. The NCP status column in PPP view shows NCP layer status per link in PPP simulation. In MLPPP simulation, it shows the status of the entire MLPPP bundle

    Payload Traffic Generation, Reception, and Verification now supported in PPP and MLPPP simulation. Network Traffic is included as a new traffic source type in both PPP simulation and MLPPP simulation. MLPPP Emulator can transmit and receive Ethernet traffic over T1 E1 links by operating either in bridge or router mode.

    For comprehensive understanding of the product, please visit the Multi-Class MLPPP Emulator webpage.

  • ISDN Emulator

    The emulator now allows the users to set various release causes during simulation. These include rejected, no user response, user busy, congested, and so on for disconnection of the particular call on the channel. At the termination end, after the call is terminated, the cause for disconnecting the call gets displayed in the Last Cause field.

    For comprehensive understanding of the product, please visit the ISDN Emulator webpage.

  • Digital Echo Canceller (DEC)

    The Digital Echo Canceller is a four-port software that supports bidirectional voice traffic between the two ends of a connection is now supported with logging option that allows to save file in *.CSV format as well as *.txt format.

    For comprehensive understanding of the product, please visit the Digital Echo Canceller (DEC) webpage.

In addition to the above, there have been many minor modifications and bug fixes to the T1E1 Software. For more details, please refer to the link What's New in Current Version.
